Description
- S7 – 7kW Rate (Single Phase)
- Model: S7-2C Variant: S7-2C-6mA-2 Tethered Type 2 Cable
- Diameter: 360 mm
- Depth: 150 mm
- Finish: anti-graffiti
- Operating Temperature: -30°C to +50°C
- Operating Humidity: 95%
- Enclosure Rating: IP54
Specifications
- Colour: Grey-Black
- Charge Protocol: Mode 3
- Rated Frequency: 50 Hz
- Over-Current Protection: internal (dynamic)
- Standby Power Consumption: <2.5 Watts
- Auto Power Balancing: enabled (excludes 22kW model)
- Rated Voltage: 230V AC phase+N
- Rated Output Current: 1 x 32
- Rated Output: 1 x 7kW
- Connection Security: secure data encryption (HTTPS)
- TCP: port 443
- Wi-Fi: (IEEE 802.11bgn) @2.4 Ghz
- Standards Compliance: LVD 2014/35/EU EMCD 2014/30/EU EN61851-1 and -22 EN61000-3 and -2 CE Certified BS7671: 2018
